| Specification | ||
| DESCRIPTION
|
REARVIEW
|
|
| NTSC | PAL | |
| Pick up Device | 1/4"Color CCD Sensor |
1/4"Color CCD Sensor |
| Number of image Pixels | 512(H)×492(V) |
512(H)×582(V) |
| Output image | Wide
Viewing Angle and Mirror |
|
| Operating Voltage | DC12V(6〜16V) |
|
| Cousumption Curent | 80mA(MAX),at
DC12V |
|
| LENS | Wide
Viewing Angle,F=2.5 |
|
| Video Output | 1.0Vp-p(75ohm),Composite |
|
| Shutter Control | IRIS(1/60,1/50~1/100,000) |
|
| Horizontal Resolution | 380TV
Lines |
|
| Min.illumination | 0.1Lux |
|
| S/N Raito | -30℃〜+70℃ |
|
| Operating Temperautre | -40℃〜+85℃ |
|
| Storage Temperautre | - |
|
| Camera Measurement | Zinc |
|
| Material | Black |
|
| Material Color | Camera2.5m,Extension
|
|
| Cable Length | 6m,Power1.5m |
|
| 弊社で装着希望の場合 | TELで問い合わせ | a/tack本社:045-595-1730 / Scondstage:045-540-3825 |
| メールで確認 | a/tack本社 l staff@a-tack.net Scondstage: 2stage@a-tack.net | |
| 通信販売でキットのみ購入 | ショッピングカートで購入 | |
